The dream Chip (keeping it close to achievable, though)

If we are talking achievable dreams, I personally wouldn’t be talking about a Proxmark.
I get the Linux:Linux relationship, but I would rather a, less bulky, more user friendly option.
However staying on that same thought path, and still engaging the achievable dream :thought_balloon:
INTERFACE
Rather than a terminal, how about an app to interface, using buttons for the common commands. One button push vs typing script. :exploding_head:

HARDWARE
The RDV4 when spread out would be relatively low profile ( I wonder if a Proxmak including Antennas could be made on a flexible PCB :thinking: ) and Re: the RDV4 having an exposed UART

Sound: Loudspeaker, 3.5mm jack & mic (jack doubles as hardware UART if killswitch 6 is deactivated)

All conveniently located near the Pogo pins

Yeah, I thought about an RDV4, would be the better option by far, albeit a very very expensive one.

I mainly was focused on a proxmark, because I’m not aware of any LF breakout boards or chips that interface over I2C or serial, and also happen to be anywhere close to as flexible as the proxmark. An LF equivalent to the PN532 in terms of support & ease of use would be nice, but I don’t know of any. If anyone does, PLEASE let me know, I’m very interested in that.

Also damn, I meant headphone jack, not USB port. Fixed in an edit. Guess that’s what happens when I try to type a long reply on 3 hours of sleep haha.

1 Like

A quick “google”

:man_shrugging:

I feel like a python gui wouldn’t be too difficult but would only work if you already had pm3 installed. Getting an easy and graphical way to install the software would seem to be much more difficult.

Maybe just stick a Proxmark Pro to the back of the phone :wink:


I tried reimplementing a few PM3 client commands in Lua and in pure Python, and it gets tricky very quickly - as in, you’re looking at reimplementing the entire client essentially. There are several problems with that:

  • The PM3’s protocol is a hodgepodge of high-level commands that get executed by the PM3’s hardware (easy to implement) and low-level raw data reads and writes that are decoded and interpreted client-side (harder)

  • The documentation is beyond sketchy (read: there isn’t one - read the code)

  • It’s a shifting target: it keeps changing from one iteration of the firmware / client to the next, which is why it’s so important to keep the two in sync.

In the end, I decided the bext course of action is to use the client as a backend. Spawn it as a separate process, send it commands through its stdin and get the results back through its stdout. And even that is not ideal: for instance, SiRFIDaL can use the PM3 as a reader, but I’ve had one report telling me it doesn’t work anymore because either one of the commands it issues it has changed, or the client’s output has changed and the regex used to recover the data it needs doesn’t match anymore.

The PM3’s software - firmware and hardware - is a maintainability, interoperability and compatibility nightmare. If it wasn’t a community project that someone kindly does on his own time, I’d be extremely pissed off with it.

I’ve had success with running a Sonny PaSoRi via NFCPy from my Pine.
And it’s one that looks like it could be flattened down pretty nicely.

Just adding 2 cents, while it’s kinda hard for me to forum up this week =P

For a full on GUI, yes.
But all you actually need is to extend a terminal.

Add one row of buttons, manage the state of the application, and present buttons to the user based on what he is doing.
One button press = pipe a command to be executed in that terminal.

For a mobile integration that hybrid solution would cover all my GUI needs to be honest.
As in,…

If I am using a proxmark, either I am “setting up shop”

  • so I want a keyboard + mouse + terminal

Or I am doing a very selkect and pre-defined set of operations, such as read then clone.

  • in which case, I just need 3/4 buttons total, and the terminal output is there only to help me double check stuff

Completely ridiculous idea because of current limitations

But imagine having chips that reacted to other chips

Be it led or a chirp

Imagine meeting another “cyborg” and our handshake is our chips actually “handshaking”

So stupid but so worth it lol

1 Like

if only we could have non-reactive safe chips…

That would be amazing!! :star_struck:

@locksmith31 has posed this previously also

OrdinarySmoggyDaddylonglegs-size_restricted giphy (16)

OR

SCANNER…
IMPLANT…
READ…
AUTHORISED…
4c1d2fe38431510e25f5736bcfa4f252

2 Likes

we kinda have that now… when shaking hands you use your thumb to probe around L0 for an implant in the person’s hand you’re shaking :slight_smile: works pretty well actually.

4 Likes

Is this some kind of left handed shake? Because that sounds pretty terrible

I can’t picture how someone would wind up with their hand on my left hand

I imagine a fist bump that makes a chirp

And this has turned into a derail

It works well unless you can’t feel any implant. Then you’re left trying to explain to a random dude why you’ve been fondling his hand with your thumb for the last 5 seconds.

1 Like

yeah… basically you shake their hand as normal with your right hand… then you grapple them to the ground and put their left arm in a leg lock… then jab your thumb into their hand repeatedly until you find a chip or the police arrive. simple really. works really well!

No no, it’s really subtle… normies don’t even notice their arm being pulled from its socket.

5 Likes

If you could make an implant that does a display like the one shown in this image how would you do it?

I’m thinking flex pcb layers for a seven segment display, a razor thin battery with a qi charger module, and probably some kind of specialized illuminating bit (don’t think smd LEDs will make the cut). Maybe OLED if power wasn’t an issue but idk.

4 Likes

Excellent idea. Do you have any experience testing prototypes like that? I’m sure the community would be able to provide some help with that.

I’ve hacked little things together over the years. I feel like this wouldn’t be too difficult to achieve. Using straight flex oled is still a long way off though, the tech just isn’t there yet. If I or someone could think of an ingenious way to get the lumins needed on such a display then the only thing left would be to figure how to implant that monster without too much scarring :joy:

1 Like

My other crazy idea: implantable proxmark3 or other device like the chameleon tiny

Key problem, battery.

it’s has to be possible though, if these guys can engineer it. someone can open source it eventually.
just found these from a cursory search.

https://www.eaglepicher.com/markets/medical-power/

edit: found this article as well. seems pretty interesting! (one of their prototypes is a flat plane :slightly_smiling_face:)
