Made good progress on my car ignition project today. I wanted to be double check how my ignition switch worked + figuring out the actual pinout, before I could finalize the board design and send it off to be made. So, I went to the junkyard, found a car the same model as mine, and spent about 45 minutes ripping out the ignition switch. Would have been easier, but I didn’t think to bring a 1 foot long socket extension with me (needed to remove the lower dash panel, had some crazy deep bolts), so I had to just cut it out from the front. Thankfully a lot of my assumptions were validated, just gonna spend some time today triple checking pinouts and making some notes on paper for continuity on each key position. It has 9 pins, but it seems that quite a few are redundant. The ignition switch obviously came with a lock I didn’t have the key for (and neither did the junkyard), but thankfully, I do locksport :stuck_out_tongue_winking_eye: I would definitely recommend anyone else do the same if they plan on doing a similar project, having a spare ignition switch to test with has been a huge help. Not having to half disassemble my dash and having to risk my car not being able to start was well worth the money. The $30 it cost will also be well worth it if it stops me from shorting something out and breaking my body control module.

In other news, I got some more PN532 breakouts ordered, and my PinePhone comes Thursday. I’ll post a write-up for the NFC case I’m making for that as well, hopefully that should only take a day to finish. 3D printing the NFC case itself will take the longest time. Assuming everything goes well with that, I’ve also started on a super basic touch NFC app for the PinePhone, just enough to pull UIDs and hopefully NDEF records. libnfc is compatible with the PN532 over I2C, so it shouldn’t be insanely awful to implement. Should be a good project for learning mobile Linux toolkits, too.

The Pinecil is still somewhere in China it seems. It shipped about a week ago, but China Post is not quick. Should definitely have paid for DHL for it, would have been well worth it it seems.
